Vortex Differential Valve 600L/Min

Vortex Differential Valve 600L/Min

Part No. VXVD
Part No.
Vortex Differential valves are ideal for use in water tanks which are filled by a pressure system controlled water pump. The valve gives a level difference which is adjustable from 50mm to 2.5m to minimise starting and stopping of the pumping system.

Outline of operation
  • The valve should be mounted at the top of the tank using a threaded tank inlet setting.
  • As the tank empties the weighted float travels down the cord until it hits the bottom stop. The valve then opens immediately to give a full flow.
  • The valve now runs constantly and the weighted float rises until it hits the upper float stop. This lifts the arm and the valve shuts down.
  • Observe the pressure that your pump runs at while the tank is filling. Set the pressure switch to turn the pump off at least one bar above the running pressure.
  • High flow
  • Easily adjustable water level differentials between on and off (50mm - 2.5 m differentials obtainable).
  • Reduces pump operation to a mininum.
  • Valve unscrews from tail for easy Valve access.
  • Ideal for all makes and models of tanks.
Choose Size

$693.30
